Mô tả sản phẩm :

TECHNICAL DATES		S 34 B	S 34 D	S 34 G	S 34 P

Working width	mm
-with 2 side brushes	mm	1450	1450	1450	1450
-with 1 side brush	mm	1150	1150	1150	1150
-only central brush	mm	850	850	850	850
Cleaning capacity up to	m2/h	8050	9300	9300	9300
Operating range	h	3
Waste tank dischange (m/idr)
Waste tank capacity	l	205	205	205	205
Max. discharging height	mm	1340	1340	1340	1340
TECHNICAL DATES		S 34 B	S 34 D	S 34 G	S 34 P

Sweeping type (front/rear)		front	front	front	front
Mechanical drive (front/rear)
Traction (motoroue/diff./hydrost.)		@NOTE7@	@NOTE7@	@NOTE7@	@NOTE7@
Forward speed	km/h	0/7	0/8.1	0/8.1	0/8.1
Filter type		/	/	/	/
Max. slope	%	12	15	15	15
Filtering surface		5.5 / 7	5.5 / 7	5.5 / 7	5.5 / 7
Central cylindrical brush speed rotation	rmp	450	480	480	480
Side brush speed rotation	rmp	83	97	97	97
Noise level	DB	80.5	81.5	81.5	81.5
Turning radius	mm	1555	1555	1555	1555
Vibrations (hand/arm)		Aw=0.675	Aw=1.85	Aw=1.85	Aw=1.85
Central brush motor
Side brush motor
ELETTRIC DATES		S 34 B	S 34 D	S 34 G	S 34 P

Power	V	36
Vacuum motor	W	250	250	250	250
Feeding		36V – 320A/h
MOTORIZATION		S 34 B	S 34 D	S 34 G	S 34 P

Feeding (diesel/fuel/gas)
Mark/model of the engine			Lombardini LDW702	Lombardini LGW627	Lombardini LGW627
N° cylinders			2	2	2
Power/rounds			17.7cv x 3600rpm	19.7cv x 3600rpm	19.7cv x 3600rpm
Cooling
WEIGHT AND DIMENSIONS		S 34 B	S 34 D	S 34 G	S 34 P

Length	mm
-with 2 side brushes	mm	2150
